Features a state-of-the-art Two-Stage Compression design. Intercooler included to lower temperature and improve efficiency. Rotors do not touch, ensuring zero wear.
Durability: No metal-to-metal contact
Efficiency: Two-stage with intercooling
Material: Stainless steel precision rotors
Completely dry compression chamber. No oil, no water, no coolant required inside. Guarantees ISO Class 0 100% oil-free air for food pharma.
Purity: Zero oil contamination risk
Design: Separate oil & air seals
Maintenance: No oil filter/separator needed
Rotors and housing are treated with a special Teflon/Molybdenum coating. High temp resistant (300°C) and corrosion-free.
Life:Prevents rust and wear
Efficiency:Optimized gap sealing
The entire system is air-cooled, eliminating the need for cooling water or towers. Simple installation and maintenance.
Convenience:No water piping needed
Design:High-efficiency intercooler
Adopts Load/Unload and Auto Start/Stop dual control modes. Automatically stops motor during low demand to save power.
Smart:Reduces unload power waste
Control:Intelligent PLC system
| Feature | Water-Injected Oil-Free | ZIQI OFD Dry Type |
|---|---|---|
| Compression Medium | Water (Risk of bacteria/corrosion) | Dry Air (100% Clean) |
| Rotor Contact | Water Film Seal | Non-Contact (Long Life) |
| Cooling Method | Water Injection | Air Cooled (Simple Install) |
| Rotor Coating | None / Ceramic | Teflon/Moly (300°C Resist) |
| Maintenance | Water Filter/Softener | Minimal Maintenance |
Representative Models (Air Cooled / Two-Stage)
| Model | Power (kW) | Pressure (MPa) | Air Delivery (m³/min) | Noise dB(A) | Connection |
|---|---|---|---|---|---|
| OFD-45A | 45 | 0.7 - 1.0 | 6.4 - 7.6 | 80±3 | DN50 |
| OFD-55A | 55 | 0.7 - 1.0 | 8.0 - 9.2 | 80±3 | DN50 |
| OFD-75A | 75 | 0.7 - 1.0 | 10.9 - 12.6 | 80±3 | DN50 |
| OFD-110A | 110 | 0.7 - 1.0 | 16.4 - 20.0 | 82±3 | DN65 |
| OFD-132A | 132 | 0.7 - 1.0 | 19.9 - 23.6 | 82±3 | DN65 |
| OFD-160A | 160 | 0.7 - 1.0 | 23.6 - 26.9 | 82±3 | DN65 |
* Data based on 380V/50Hz models. Water-cooled versions (W series) available for >200kW.
| Model | Max Pressure | Air Delivery | Motor Power | Dimension (mm) (L × W × H) |
Weight (kg) |
Noise dB(A) |
Outlet | |||
|---|---|---|---|---|---|---|---|---|---|---|
| MPa | bar | m3/min | cfm | kW | HP | |||||
| ?? Air Cooling Series (OFD-A) | ||||||||||
| OFD-45A | 0.7 | 7 | 7.6 | 268 | 45 | 60 | 2150×1550×1840 | 2400 | 80±3 | DN50 |
| 0.8 | 8 | 6.6 | 233 | |||||||
| OFD-55A | 0.7 | 7 | 9.2 | 324 | 55 | 75 | 2150×1550×1840 | 2600 | 80±3 | DN50 |
| 0.8 | 8 | 9.1 | 321 | |||||||
| OFD-75A | 0.7 | 7 | 12.6 | 445 | 75 | 100 | 2350×1650×1840 | 2800 | 80±3 | DN50 |
| 0.8 | 8 | 11.6 | 410 | |||||||
| OFD-90A | 0.7 | 7 | 13.4 | 473 | 90 | 120 | 2350×1650×1840 | 3400 | 80±2 | DN50 |
| 0.8 | 8 | 13.3 | 469 | |||||||
| OFD-110A | 0.7 | 7 | 20.0 | 706 | 110 | 150 | 2350×1650×1840 | 3400 | 82±2 | DN65 |
| 0.8 | 8 | 18.8 | 664 | |||||||
| OFD-132A | 0.7 | 7 | 23.6 | 833 | 132 | 180 | 2850×1850×1910 | 3450 | 82±2 | DN65 |
| 0.8 | 8 | 22.2 | 784 | |||||||
| OFD-160A | 0.7 | 7 | 26.9 | 950 | 160 | 215 | 2850×1850×1910 | 3550 | 82±2 | DN65 |
| 0.8 | 8 | 25.5 | 900 | |||||||
| ?? Water Cooling Series (OFD-W) | ||||||||||
| OFD-200W | 0.7 | 7 | 33.5 | 1183 | 200 | 270 | 3150×2200×2200 | 4500 | 85±3 | DN100 |
| 0.8 | 8 | 33.4 | 1179 | |||||||
| OFD-250W | 0.7 | 7 | 46.8 | 1652 | 250 | 340 | 3150×2200×2200 | 5200 | 85±3 | DN100 |
| 0.8 | 8 | 45.7 | 1613 | |||||||
| OFD-315W | 0.7 | 7 | 51.5 | 1818 | 315 | 428 | 3450×2450×2250 | 6600 | 90±3 | DN100 |
| 0.8 | 8 | 51.3 | 1811 | |||||||
| OFD-355W | 0.7 | 7 | 58.5 | 2065 | 355 | 482 | 3450×2450×2250 | 6800 | 90±3 | DN100 |
| 0.8 | 8 | 57.9 | 2044 | |||||||
